Description
Sales of Floating Crane1. 1200 Tons - 2011 BLT , 78m LOA
FLOATING CRANE (SHEER LEG TYPE)
FLAG: KOREA
CLASS: KR, +KRS OC / COASTAL AREA, BARGE PONTOON / NON-SELF PROPELLED
BUILT: JULY 12, 2011, KUM GWANG INDUSTRIAL MACHINERY CO LTD., KOREA
LOA/L/B/D: 78.00 / 74.90 / 32.00 / 5.40 M
GRT/NRT: 4,569 / 1,364 T
DWT/DRAFT: 6,233 / 3.7 M
MAIN G/E: CATERPILLAR 860 PS X 3 SETS
G/E: DOOSAN 170 PS X 2 SETS
LIFTING CAPACITY: TOTAL SWL 1,200 T (300 T X 4 SETS)
MAIN CRANE: PIPE JIB LUFFING TYPE, LIFTING HEIGHT (65 DEG): 90.0M(FWD), 84.8M(AFT)
WINCH CAPACITY: 50 T X 16 M/MIN X 2 SETS
ENCLOSED SPACE CAPACITY: 16,005.503 CBM
DECK CRANE: SUSAN INDUSTRY SCS736, 6 T X 2.6 M X 1 SET
CREW COMPLEMENT: 10 P
TANK CAPACITY: FO 308.740, FW 628.56, BW 4,700 CBM
-------------------------------------------------------------
2. SALKO 600 - 600 Tons - 1970 BLT, 57M LOA
1200 TLC FLOATING CRANE (SALKO1200)
KUMYONG No.1300
NAVIGATION AREA: GREATER COASTING AREA
PARTICULAR [FC-164] [11102022.VED006.1041]
* LIFTING CAPACITY : 1,200 TON(S.W.L)
* BLT : SEP. 2010 IN KOREA
* CLASS/FLAG : KR / KOREA
* GROSS TONNAGE : 4,547 TON
* LOA X BREADTH X DEPTH : 78.0M / 32.0M / 5.4M
* CRANE SYSTEM
- PIPE JIB LUFFING TYPE (dia 2200×dia 4000×107M) : 1 SET / FORE. UPPER DECK
- GATE POST TYPE - BACK TOWER : 1SET / AFT. UPPER DECK
- No.1, 2 HOOK (DEGREE : 65°)
S.W.L. : 300 T×2 SETS=600 T
HEIGHT : 90.0 M
OUT REACH : 37.6 M
- No.3, 4 HOOK (DEGREE : 65°)
S.W.L : 300 T×2 SETS=600 T
HEIGHT : 84.8M
OUT REACH : 32.9M
* HYDRAULIC MACHINERY SYSTEM - DIESEL ENGINE FOR HYD' POWER UNIT DRIVEN MAKER : CATERPILLAR MODEL : CAT 3412C CAPACITY : 843 PS (831 BHP) × 1800 RPM QTY : 3 SETS
* AUX' ENGINE & GENERATOR - AUX' ENGINE(DIESEL) : 2 SETS TYPE : AD196TIS / 4 CYCLE CAPACITY : 270 BHP×1800 RPM - GENERATOR : 2 SETS TYPE : PNL-BRUSHLESS / SELF EXCITING CAPACITY : AC445×220KVA(176 KW)×60 HZ
* INSPECTION/DELIVERY : KOREA
KUM YONG NO.1700 - NIMATA FLOATING CRANE 1500 T
SHEERLEG TYPE, NIMATA FLOATING CRANE
BUILT: MAR 2009, IN KOREA
FLAG: BUSAN, KOREA
CLASS: KR, +KRS 0C / COASTAL AREA
BARGE, PONTOON / CRANE NON SELF-PROPELLED
LOA x B x D: 85.00 x 42.00 x 7.00 M
DRAFT: 4.6 M
DWT / GRT : / 8565 T
M.ENG : CATERPILLAR 843 HP X 3 SETS
GENERATORS: DOOSAN 270 HP x 2 UNITS
LIFTING CAPACITY: 1500 TON
WOG / SUBJECT TO AVAILABILITY
FURTHER DETAILS TO NAMED INTEREST ONLY
