BRIEF DETAILS

BUILT

:

2010 / MALAYSIA

CLASS

:

NK

LOA

:

29.92 M

MOULDED BREADTH

:

9.76 M

MOULDED DEPTH

:

4.70 M

DRAFT

:

3.352 M

GRT/NRT

:

338/102

DEADWEIGHT

:

218

SPEED

:

11 KNOTS

BOLLARD PULL

:

40 TONNES

COMPLEMENT

:

10 MEN

MACHINERY

MAIN ENGINE

:

2 X CUMMINS KTA50-M2, 1600HP @ 18000RPM

GENERATOR

:

2 X CUMMINS 6BT5-9-D(M) 78KW @ 1500RPM

GEARBOX

:

2 X REINTJES WAF 665, RATIO OF 5.95: 1

TANK CAPACITY

FUEL OIL

:

216 M³

FRESH WATER

:

32 M³

BALLAST TANK (FRESH WATER)

:

70 M³

PROPULSION

PROPELLER

:

2 X 4-BLADED MANGANESE BRONZE PROPELLER, 2350MM IN DIAMETER

SHAFT

:

2 X SEA WATER LUBRICATION SHAFT

TUNNEL THRUSTER

:

1 X HYDRAULIC THRUSTMASTER THRUSTER 36TT250L

DECK EQUIPMENT

WINDLASS

:

1 X 3 TON HYDRAULIC ANCHOR WINDLASS

ANCHOR

:

2 X 660KG EACH

TOWING HOOK

:

1 X 40 TON

TOWING WINCH

:

1 X 30 TONNE HYDRAULIC WINCH

FIFI SYSTEM

:

2 X FIRE MONITOR X 600M3 PER HOUR AT 140M

BRIEF SPECIFICATION (14092026.VED077.0944)

BUILT
LAUNCHED

:
:

2012 / MALAYSIA
2026

CLASS

:

BV

L.O.A.

:

40.0 M

BREADTH MLD

:

11.8 M

DEPTH MLD

:

4.6 M

DESIGNED DRAFT

:

3.8 M

DEADWEIGHT

:

345 TONNES

BOLLARD PULL

:

45 TONNES

TRIAL SPEED

:

11 KNOTS

ACCOMMODATION

:

20 MEN

TANK & DECK CAPACITY

FUEL OIL

:

300.00 M³

FRESH WATER

:

80.00 M³

DECK LOADING

:

5 TONNES/M³

CLEAR DECK AREA

:

APPROX. 150 M³

PROPULSION SYSTEMS

MAIN ENGINE

:

2 X MITSUBISHI S16R-MPTK MARINE DIESEL ENGINE RATED 1,850BHP @ 1,650RPM

GENERATOR

:

3 X CAT C6.6 MARINE DIESEL ENGINE C/W ALTERNATOR 143KW, 415V, 3PH, 1500 RPM

PROPELLER & KORT NOZZLE

:

2 X SOLID 4 BLADES MANGANESE BRONZE PROPELLER

DECK MACHINERY & EQUIPMENT

ANCHOR WINDLASS

:

30MM ELECTROHYDRAULIC ANCHOR WINDLASS C/W DOUBLE GYPSY

ANCHOR

:

2 X 900-KGS STOCKLESS BOWER ANCHOR

TOWING WINCH

:

1 X 60-TONS DRUM PULL @ 6M/MIN

TUGGER WINCH

:

2 X 5-TONS X 10M/MIN SINGLE DRUM HYDRAULIC TUGGER WINCH

SHARK JAW

:

1 X 200-TONS SCHEMATIC HYDRAULICALLY OPERATED ANCHOR HANDLING FORK

TOWING PIN

:

1 X 200-TONS SCHEMATIC HYDRAULICALLY TOWING PIN

CAPSTAN

:

2 X 5-TON X 12M/MIN HYDRAULIC VERTICAL CAPSTAN C/W LOCAL CONTROL

STERN ROLLER

:

1 X 150-TON SWL MILD STEEL STERN ROLLER

BOW THRUSTER SYSTEM

:

1 X 5.0 TONNES SCHOTTEL BOW THRUSTER FPP

RADIO & NAVIGATION EQUIPMENT

GMDSS 2-WAY VHF TRANSCEIVERS

:

2 X MCMURDO R2

RADAR

:

1 X FURUNO FAR-2117 MK3

GPS NAVIGATOR

:

1 X FURUNO GP-150

EPIRB

:

1 X MCMURDO E5, 406 MHZ

SATELLITE COMPASS

:

1 X FURUNO SC-50

FIRE FIGHTING & LIFE SAVING EQUIPMENT

FIRE PUMPS

:

1200 M3/HR BY PTO

FIRE MONITORS (WATER/FOAM)

:

2 UNITS WITH REMOTE CONTROL

LIFE RAFT

:

20 PERSONS X 2 SETS

LIFE BUOY-RING

:

8 SETS

BRIEF DETAILS (14092026.VED077.0915)

YEAR BUILT

:

2012

CLASS

:

RINA

LENGTH

:

32 M

BREADTH (MLD)

:

10 M

DEPTH (MLD)

:

5.5 M

MAX DRAFT

:

4.3 M

GRT/NRT

:

393/118  TONNES

MAX SPEED

:

10 KNOTS

BOLLARD PULL

:

50 TONNES

ACCOMMODATION

:

12 MEN

MACHINERY

MAIN ENGINE

:

2 X YANMAR 6EY26W @ 4,000BHP/750 RPM

AUXILIARY ENGINE

:

2 X CATERPILLAR C6.6

PROPULSION

:

2 X BERG. PROPULSION BAT 523

TANK CAPACITY

FUEL & OIL

:

145 TONNES (APPROX)

FRESH WATER

:

32 TONNES (APPROX)

DECK MACHINERY

HYDRAULIC COMBINED

ANCHOR WINDLESS/TOWING WINCH

EQUIPPED WITH FIFI 1

BRIEF DETAILS (14092026.VED077.0859)

BUILT

:

2019

FLAG

:

INDONESIA

CLASS

:

BV

LENGTH

:

27.00 M

BREADTH

:

8.20 M

DEPTH

:

3.650 M

DRAFT

:

2.90 M

GRT/NRT

:

183/54

SPEED

:

12 KNOTS

BOLLARD PULL

:

32

ACCOMMODATION

:

TOTAL 12 MEN

MAIN PROPULSION

MAIN ENGINES

:

2 X CATERPILAR C32 ACERT 746 KW (1000 BHP) @1800RPM

PROPELLERS

:

MANGANESE BRONZE

MAIN GENERATORS

:

2 X CUMMINS 48 KW

TANK CAPACITY

FUEL OIL

:

105 TONS

FRESH WATER

:

32 TONS

DECK MACHINERY EQUIPMENT

ANCHOR WINDLASS

:

1 X HYDRAULIC ANCHOR WINDLASS C/W DOUBLE GYPSY DRUM

ANCHOR

:

2 X 480 KG STOCKLESS BOW ANCHOR

TOWING HOOK

:

1 X 30 TONS C/W QUICK RELEASE

KORT NOZZLES

:

2.03M X 2

VERTICAL CAPSTAN

:

HYDRAULIC 3 TONS

NAVIGATION & EQUIPMENT

ECHO SOUNDER

:

1 UNIT

EPIRB HY-EP500

:

1 UNIT

NAVTEX SAMYUNG SNX300

:

3 SETS

INMARSAT C SAILOR 6110

:

1 SET
